Back Pressure Regulator 6000 psi 1/4" FNPT to 1/4" MNPT

$78.00

Anodized aluminum back pressure regulator, 1/4" FNPT to 1/4" MNPT. Maximum rated pressure: 6000 psi (414 bar). Fixed outlet pressure: 1900 psi (131 bar). In operation the back pressure regulator maintains its set pressure upstream and allow just enough gas flow to hold this pressure. Set pressure is pressure at the inlet port when gas is flowing through the regulator. The gauge connected to the outlet gauge port does not read set pressure; it reads pressure of the tank being filled downstream of the regulator.

SKU

1310

Details

Also known as a priority valve, the model 1310 is a fully balanced, economical regulator. It serves a wide variety of uses, however its main use is on small compressors. The regulator will improve moisture separator efficiency and filter life as much as 450%. This is done by maintaining pressure in the separator and filter at about 1800 psi when tank pressure is lower.

Specifications

Type	Back pressure regulator
Special Features	Non-adjustable
Maximum Rated Pressure	6000 psi
Outlet Pressure Setting	1900 psi
Inlet Port Size	1 ea 1/4" FNPT
Outlet Port Size	1 ea 1/4" MNPT
Outlet Pressure Rating	6000 psi
Flow Capacity	1 to 10 SCFM
Leakage	Zero external; 0.05 SCFM internal
Weight	2.7 oz (76 g)
Overall Length	2.5"
Hex Diameter	1"
Minimum Temperature	-15ºF (-26ºC)
Body Material	Anodized Aluminum
Internal Materials	Brass
Seal Materials	Viton
Flow Coefficient (Cv)	0.35
