Booster Mixed/Single Gas Travel Kit Series
Mounted in a watertight Pelican case, the Booster Mixed or Single Gas Travel Kit is designed for the traveling diver who requires partial pressure nitrox or technical trimix blends in locations where such services are not otherwise available. Choose from one of three available Haskel boosters: MSB9000, AG30 or AGT15/30.
The Nuvair Booster Mixed/Single Gas Travel Kit is manufactured at our California production facility. Based on your gas needs, choose from one of the three available Haskel boosters. We install all kit components in a watertight 24.9 x 23.7 x 13.1" (63 x 60 x 33 cm) Pelican iM2875 case with wheels and travel handle. The kit comes oxygen service ready. Please contact the Nuvair sales team for a quote on non-oxygen booster travel kits.
The stainless-steel MULTIGAS fill panel includes the following components:
- (3) HP needle valves
- (3) Inline check valves
- (4) 3" (7.62 cm) HP quick disconnects rated to 5200 psi (358 bar)
- (1) Digital pressure gauge (psi/bar)
- (1) Polymer flow control needle valve
- (1) Booster drive gas pressure gauge
- (1) Booster drive gas pressure LP-LP regulator
- (1) LP quick disconnect for booster drive gas
The stainless-steel SINGLE fill panel includes the following components:
- (1) HP needle valve
- (1) Inline check valve
- (2) 3" (7.62 cm) HP quick disconnects rated to 5200 psi (358 bar)
- (1) Digital pressure gauge (psi/bar)
- (1) Polymer flow control needle valve
- (1) Booster drive gas pressure gauge
- (1) Booster drive gas pressure LP-LP regulator
- (1) LP quick disconnect for booster drive gas
Advantages
| Choose from the booster that best fits your needs: ◦ MSB9000 Mini Sport ◦ AG30 or ◦ AGT15/30 |
| Inlets for one or three gasses with quick disconnects and oil-free pressure gauges: ◦ Oxygen ◦ Helium, and/or ◦ OCA Air |
| Large 4" digital final pressure gauge |
| Quick disconnect for final output fill whip |
| Standard quick disconnect for first stage connection to drive from scuba bottle |
| Speed control needle valve for booster |
Unless special ordered, all components are O2 cleaned to Nuvair Oxygen Clean Standards. All gauges are oil-free for oxygen safety.
Specifications
| Model | NUVB-KIT-9000 | NUVB-KIT-AG30X | NUVB-KIT-AG30X-1G | NUVB-KIT-AGT15/30 |
|---|---|---|---|---|
| Drive | 4" (10cm) | 5.75" (15cm) | 5.75" (15cm) | 5.75" (15cm) |
| Gasses | Multiple (≤3) | Multiple (≤3) | Single | Multiple (≤3) |
| Ratio | 25:1 | 30:1 | 30:1 | 15:1 |
| Weight | 70 lb (32 kg) | 80 lb (36 kg) | 66 lb (30 kg) | 90 lb (41 kg) |
| Maximum Inlet Pressure | 4500 psi (310 bar) | 4500 psi (310 bar) | 4500 psi (310 bar) | 5000 psi (345 bar) |
| Maximum Rated Outlet Pressure | 4500 psi (310 bar) | 4500 psi (310 bar) | 4500 psi (310 bar) | 5000 psi (345 bar) |
| Volume per Cycle | 1.232 cu in (20.2 mL) | 3.1 cu in (50.8 mL) | 3.1 cu in (50.8 mL) | 6.2 cu in (101.6 mL) |
| Maximum Air Drive Pressure | 150 psi (10.3 bar) | 4500 psi (310 bar) | 4500 psi (310 bar) | 9000 psi (621 bar) |
| Minimum Gas Supply Pressure | 100 psi (7 bar) | 100 psi (7 bar) | 100 psi (7 bar) | 50 psi (3.5 bar) |
Nuvair is an Authorized Haskel® Distributor
Nuvair sells only genuine parts and equipment manufactured by Haskel® International. Do not be fooled by cheap aftermarket copies of original Haskel® equipment. Items labeled “replacement” or “alternative” are not manufactured by Haskel®.
Some Haskel parts may not be available for immediate shipping. Please contact the sales team for estimated lead times.
