Nuvair CAN-35 High Pressure Filter Canister Series
SKU
CAN-35 Series
The CAN-35 Series high-pressure filter canisters fit 27" x 2.75" filter elements. Housing pressure rating: 6000 psi (414 bar). Two thread versions available.
The Nuvair CAN-35-6000 has a maximum working pressure of 6000 psi (414 bar). Each canister is serialized. Housing life: 10 years. Two versions available.
Nuvair CAN-35-6000 Specifications
| Housing Life | 10 years |
|---|---|
| Maximum Working Pressure | 6000 psi (414 bar) |
| Temperature Minimum/Maximum | 14°F · 122°F |
| External Dimensions | 32.5" L x 3.75" W |
| Filter Element Dimensions | 27" L x 2.75" W |
| MAXIMUM ALLOWABLE CYCLES | WORKING PRESSURE |
| 85,000 | 2000–3600 psi |
| 25,000 | 3601–4700 psi |
| 20,000 | 4701–6000 psi |
| CAN-35 SERIES VERSIONS | |
| CAN-35-6000 | 1/4" NPT threads on base for inlet and outlet |
| CAN-35-6000-BOSS | Boss threads on base for inlet and outlet |
The Gotco GO-CAN-35-6000 housing is no longer in production. Limited quantities available.
