Champion LP R15 Framed: Diesel, Gas or Electric
Champion R15 continuous-duty frame mounted pump with electric motor or gas engine. Our framed models offer a variety of designs to meet your needs. The standard package has a one-gallon surge tank, ball valve output, over-pressure valve, drain valve, large air aftercooler, check valve, gate valves and plumbing.
The frame is made with 6061 aluminum and has an enclosed bottom, center lifting eye, handles and wheels, making it easy to wheel on and off the job. All equipment is inset; compressor and diesel are mounted on an aluminum plate and have independent vibration absorption mounts. A separate gas receiver (volume tank) and breathing air filtration are needed for diver use.
SKU
LP-R15
Features
- Reliable diesel motor
- High quality two-stage splash lubricated pump
- Centrifugal unloader - loadless starts
- Simple to operate, reliable and versatile
Options
- Electric motor in any volt or phase
- Honda gas engine
- Low pressure regulator for downstream Pressure
- Air aftercooler
- CO and/or O2 analyzers
- Audible and visual high temperature alarm
- Low oil shutdown
- High temperature shutdown
- Breathing air filtration
- ASME rated 30 gal or larger gas receiver (volume tank)
Specifications
| Model | Diesel SKU LP-R15DY |
Electric SKU LP-R15E |
Gas SKU LP-R15H |
|---|---|---|---|
| Charging Rate |
20 CFM @ 175 psi 538 L/min @ 12 bar |
23 CFM @ 175 psi 651 L/min @ 12 bar |
20 CFM @ 175 psi 538 L/min @ 12 bar |
| Power | 10 hp (7.5 kW) Yanmar engine | 7.5 hp (5.6 kW) motor | 11 hp (8.2 kW) Honda engine |
| Dimensions (L x W x H) |
29 x 48 x 38 in (74 x 122 x 96 cm) |
||
| Weight | 510 lb (230 kg) | ||
| Lubrication | Splash | ||
| Air Quality | Grade D breathing air (with breathing air filtration option) | ||
