Hankison E9-32 Filter Element
Grade 9 Filter: Separator. Mechanical for bulk liquid removal plus a 3.0 micron coalescer. 5 ppm w/w maximum remaining oil content. Two stainless steel orifice tubes provide 10 micron mechanical separation in the first stage of filtration, and an in-depth fiber media captures solid and liquid particles to 3 microns in the second stage of filtration.
- Buy 6 for $365.16 each and save 15%
- Buy 10 for $343.68 each and save 20%
Nuvair is an Authorized Hankison® Distributor
Nuvair sells only genuine parts and equipment manufactured by SPX Flow Hankison®. Do not be fooled by cheap aftermarket copies of original Hankison® equipment. Items labeled “replacement” or “alternative” are not manufactured by SPX Flow Hankison®.
Features
| Withstands temperatures to 150°F (66°C) |
| Push-on elements provide simple replacement |
| Piston type seals keeps unfiltered air from bypassing element |
| Stainless steel, corrosion resistant inner and outer core > Low resistance to flow > Seam welded durability |
| Matrix blended fiber media > Large, effective surface area ensures high efficiencies and minimizes pressure drop |
| Coated, closed cell foam sleeve > Resists chemical attack from oils and acids > Ensures high efficiencies by preventing re-entrainment of coalesced liquids |
| Chemically resistant end caps |
| Silicone free |
Specifications
| Model Size | 32 |
|---|---|
| Filter Element Grade | 9: Separator |
| Model | E9-32 |
| Stainless Steel Element | NO |
| Flow Rating | 250 SCFM |
| Design Temp | 150°F |
| Weight | 1 lb |
Filter efficiency has been established in accordance with CAGI standard ADF400 and is based on 100°F (38°C) inlet temperature.
This item may not be in stock. If an urgent shipment is required, please contact the sales team for estimated lead times.
