Two-Way Condensate Drain Series
The IWPT series of normally closed (N/C) two-way condensate drain valves come in eight (8) different configurations to meet your specific requirements. Choose from 12VDC, 110 or 220VAC; 50 or 60Hz, and 1/4 or 1/2 in NPT port size in high- and low-pressure models. Low-pressure "Automatic Condensate Drains" are equipped with timers. The adjustable timers allow users to select drain intervals between 0.5 and 45 minutes, with a discharging time of 1.5 to 10 seconds. Environmentally protected with a wide temperature operating range.
SKU
IWPT Series
Product Selection
| SKU | NPT Port Size | Voltage | Hertz | Working Pressure | Valve Body | Timer |
|---|---|---|---|---|---|---|
| IWPT16-1/2NPT220V60H | 1/2 in | 220 AC | 60 | 232 psi (16 bar) | Forged brass | Yes |
| IWPT16-1/4NPT110V60H | 1/4 in | 110 AC | 60 | 232 psi (16 bar) | Forged brass | Yes |
| IWPT16-1/4NPT220V50H | 1/4 in | 220 AC | 50 | 232 psi (16 bar) | Forged brass | Yes |
| IWPT16-1/4NPT220V60H | 1/4 in | 220 AC | 60 | 232 psi (16 bar) | Forged brass | Yes |
| IWPT-300-110V | 1/4 in | 110 AC | 60 | 4351 psi (300 bar) | Forged brass | No |
| IWPT-300-12VDC | 1/4 in | 12 DC | 60 | 4351 psi (300 bar) | Forged brass | No |
| IWPT-300-220V | 1/4 in | 220 AC | 60 | 4351 psi (300 bar) | Forged brass | No |
| IWPT-S-300-110V* | 1/4 in | 110 AC | 60 | 4351 psi (300 bar) | Stainless steel | No |
Specifications
| Timer Interval Time | 0.5 to 45 minutes - adjustable | Type | 2/2-way direct acting |
| Timer Discharging Time | 0.5 to 10 seconds - adjustable | Orifice | 4.5 mm orifice (High pressure 2.0mm) |
| Current Consumption | 4mA maximum | Maximum Media Temperature | 194°F (90°C) |
| Environmental Protection | IP65 IP65,NEMA4, IP65-EN60529 | Defend Grade | IP65, NEMA4 |
| Environmental Temperature | -40 to +122°F (-40 to +50°C) | Insulation | Thermal Group H 392°F (200°C) |
| Housing Material | ABS plastic | Valve / Seals | Forged brass *Stainless steel FPM (Viton) seals |
| Connection | DIN43650A /DIN 43650 - A/ISO 4400 | Mounting Positions | Horizontal or vertical |
| Indicator Lights | Green = on; Red = off |
