Bamax LP Gas Mini Tech w/ Framed 30-gal Tank

This hybrid, gas-powered Bamax Mini Tech is mounted to a framed and integrated 30-gallon ASME receiver.  The Bamax BX59 low-pressure compressor is powered by a pullstart Honda¹ GX270 8.5 hp engine. Equipped with a three-stage Hankison breathing air filtration system, the BX59 delivers 20 CFM @ 159.5 psi (566 L/min @ 11 bar) and is suitable for medium duty applications. Includes a 15-foot remote air intake quick-disconnect assembly with filter.

SKU
LP-BX59-7082

Specifications

 SKU LP-BX59-G (Mini Tech) 7082 (Framed Volume Tank)
Cylinders / Stages 2 / 2
Air Delivery 21 CFM @ 160 psi (595 L/min @ 11 bar)
Max Operating Pressure 165 psi (11 bar)
Engine 8.5 hp Honda GX 270¹
Air Tank Capacity   30-gal horizontal ASME tank
Unit Dimensions (L x W x H) 48 × 32 × 61" (122 x 81 x 155 cm)
Unit Weight 420 lb (191 kg)
Compressor Type Splash lubricated 2-stage
Frame Marine grade 6061 aluminum Marine grade 6061 aluminum
Compressor Plate Stainless steel
Compressor Intake Remote air intake for Bamax (NUVRAI-BX)

Bamax OEM/Distributor

Nuvair offers authentic parts and equipment manufactured by Bamax. Beware of inexpensive aftermarket imitations labeled as "replacement," "OEM equivalent," "compatible," or "alternative," as they are not made by Bamax srl. Due to size, weight, or specific requirements, some Bamax products may not be available for online purchase, and others may have extended lead times. To confirm compatibility with your existing equipment or to ensure the product meets your needs, please contact the Nuvair Sales Team for ordering assistance by email or phone.

¹ All gasoline-powered breathing air compressors manufactured by Nuvair are now equipped with Predator® engines.
