MCH6 EM Silent Compressor
Designed for filling single cylinders, the MCH6 EM Silent is enclosed in a silenced cabinet for quieter operations. The control panel is easy to reach and simple to use. MCH6 compressors are not intended for filling cascade storage systems of any kind.
SKU
SC000146 / SC000147
Features
- Breathing air filtration
- Hour meter
- 4-foot filling hose with valve
- Auto drain with condensate tank
- Autostop and emergency kill switch
- Silenced container
- Stainless steel interstage and aftercoolers
Options
- 50 Hz, 400 V or 230 V available
- Available Fill Devices:
- International yoke
- DIN200-300 bar
- DIN300 bar
- SCBA
- Paintball
Specifications
| Model | MCH6 Silent | |
|---|---|---|
| Fill Time* | 23 minutes | |
| Charging Rate* | 3.4 SCFM (96 L/min) | |
| CFM FAD | 2.8 CFM (80 L/min) | |
| 230 V / E1 / 60 Hz | 16 A 3 hp (2.2 kW) SKU SC000146 |
|
| 115 V / E1 / 60 Hz | 29 A 3 hp (2.2 kW) SKU SC000147 |
|
| Working Pressure | 3300-4300 psi (232-300 bar) | |
| Dimensions (L x W x H) |
27.4 x 27.5 x 43.3 in (67 x 70 x 110 cm) |
|
| Net Weight | 186.3 lb (84.5 kg) | |
| Noise LpA | 66 dB | |
| Number of Stages | 4 | |
| Number of Fill Hoses | 1 | |
*Based on 80 cu ft cylinder from 500 to 3000 psi.
