Mini Silent High Pressure Air Compressor
The Coltri Mini Silent series of high pressure air compressors use compact, soundproofed cabinets and are driven by three-phase electric motors operating on up to 230, 415 or 480 volts. Its completely automatic operation ensures the compressor switches off when the maximum pressure set on the dial-a-pressure switch is reached. The condensate periodically drains through automatic pneumatic valves into a collection tank. Due to its small footprint, this compressor is great for use in boats and shops. The MCH13 pumps 8.4 SCFM (238 L/min) at 5000 psi (345 bar); the MCH16 delivers 11.3 SCFM (320 L/min) at 5000 psi (345 bar).
SKU
8034 / 8034-13
Features
- Motor starter
- Automatic condensate drains
- Dial-a-pressure switch
- Automatic stop
- Hour meter
- Soundproof cabinet
- External oil sight gauge
- 5000 psi (345 bar) maximum pressure
- Grade E filtration
- Two (2) fill whips
- Stainless steel intercoolers
Options
- High temperature shutdown
- Low oil shutdown
- Interstage pressure gauges
- Visual CO/moisture indicator
- Additional filtration
Specifications
| Model | MCH13 | MCH16 |
|---|---|---|
| Fill Time* | ~11 minutes | ~9 minutes |
| Charging Rate* | 8.4 SCFM (238 L/min) | 11.3 SCFM (320 L/min) |
| CFM FAD | 7 CFM (200 L/min) | 9.4 CFM (266 L/min) |
| Motor | Three-phase electric | Three-phase electric |
| 208-230 V / E3 / 50 Hz | 14 A SKU 8034.5-13 |
22 A SKU 8034.5 |
| 208-230 V / E3 / 60 Hz | 14 A SKU 8034.2-13 |
22 A SKU 8034.2 |
| 380-415 V / E3 / 50 Hz | 8 A SKU 8034.6-13 |
12.6 A SKU 8034.6 |
| 440-480 V / E3 / 60 Hz | 8 A SKU 8034.3-13 |
10 A SKU 8034.3 |
| Motor Power | 5.5 hp (4 kW) | 7.5 hp (5.5 kW) |
| Max. Op. Pressure | 5000 psi (345 bar) | 5000 psi (345 bar) |
| RPM | 1370 | 1450 |
| Number of Stages | 3 | 3 |
| Number of Fill Hoses | 2 | 2 |
| Condensate Drain | Automatic | Automatic |
| Fill Pressure Stop | Automatic | Automatic |
| Sound Level @ 3 m | 72 dB | 75 dB |
| Dimensions (L x W x H) |
29.5 x 28.3 x 41.7 in (75 x 72 x 106 cm) |
29.5 x 28.3 x 41.7 in (75 x 72 x 106 cm) |
| Weight | 356 lb (161 kg) | 356 lb (161 kg) |
| Lubrication | Splash lubrication, capacity (2) 1.8 L | |
| Air Quality | DIN 3188 - CGA Grade E - NFPA 1500 - EN12021 | |
*Fill time based on 80 cu ft cylinder from 500 to 3000 psi.
