Mini Tech Electric Air Compressor
The Coltri/Nuvair Mini Tech high pressure (5000 psi / 345 bar) electric-powered air compressor can be used in a wide variety of continuous duty applications including breathing air and industrial air use. Compact in design with foldaway handles, the Mini Tech is portable and easy to lift. On-board Grade E air purification comes standard for breathing air quality output. With several options available to meet your specific needs, the portability and dependability of the electric powered HP Mini Tech MCH13 or MCH16 makes this the compressor for you.
The Coltri/Nuvair Mini Tech electric air compressor uses a pumping unit that is made from top quality materials; connecting rods from aluminum alloy, stainless steel intercoolers and aftercoolers that are more than four meters in length, and cylinders of special cast iron. Designed for continuous duty use, the marine grade 6061 aluminum frame is corrosion resistant, rigid and yet lightweight.
Features
- Built for continuous duty use
- 5000 psi (345 bar) maximum pressure
- Grade E breathing air filtration
- Two (2) fill whips
- Compact frame
- Stainless steel intercoolers
- 6061 marine grade aluminum frame
Options
- Motor starter
- Automatic condensate drains
- Pressure switch
- Hour meter
- High temperature shutdown
- Upgraded filtration
- Low oil shutdown
- Tropical Plus compressor block with oil pump
- Interstage pressure gauges
- Stainless steel frame
- Lifting eyes
- Visual cabon monoxide/moisture Indicator
Specifications
| Model | Mini Tech MCH13 | Mini Tech MCH16 |
|---|---|---|
| Fill Time** | ~11 minutes | ~9 minutes |
| Charging Rate** | 8.4 SCFM (238 L/min) | 11.3 SCFM (320 L/min) |
| CFM FAD | 7 CFM (200 L/min) | 9.4 CFM (266 L/min) |
| 230 V / E1 / 50 or 60 Hz |
23 A 5 hp (3.7 kW) |
30.3 A 7.5 hp (5.5 kW) SKU 8037.1* |
| 230 V / E3 / 50 or 60 Hz | 13.1 A 5 hp (3.7 kW) SKU 8040.2* |
19.4 A 7.5 hp (5.5 kW) SKU 8037.2* |
| 440 V / E3 / 50 or 60 Hz | 6 A 5 hp (3.7 kW) SKU 8040.3* |
9 A 7.5 hp (5.5 kW) SKU 8037.3* |
| RPM | 1200 | 1450 |
| Sound Level @ 3 m | 81 dB | 82 dB |
| Max Operating Pressure | 5000 psi (345 bar) | |
| Number of Stages | 3 | |
| Number of Fill Hoses | 2 | |
| Condensate Drain | Manual (auto optional) | |
| Dimensions (L x W x H) |
45.5 x 22.25 x 25.75 in (116 x 57 x 65 cm) |
|
| Weight | 320-421 lb (145-191 kg) | |
| Lubrication | Splash lubrication, capacity 1.8 L | |
| Air Quality | DIN 3188 - CGA Grade E - NFPA 1500 - EN12021 | |
*Part number reflects 60 Hz models, inquire about 50 Hz models.
**Based on 80 cu ft cylinder from 500 to 3000 psi.
