Traveler II Portable Turnkey Nitrox Generation System
This portable, turnkey nitrox system is built for the enriched air diver who wants tank fills on-the-go. Powered by either gas engine or 220-volt electric motor, the Nuvair Traveler II delivers air or generates nitrox up to 40% oxygen (EANx40) at 4.2 SCFM (119 L/min). Say goodbye to repeated trips to the dive shop for expensive nitrox refills! Fill your standard 80 cu ft cylinder to 3000 psi (207 bar) at home, on vacation or offshore in just 22 minutes. The Traveler II is manufactured at Nuvair's California production facility.
SKU
7052G / 7052E
Features
- Four-stage 4.2 SCFM high pressure (HP) compressor
- LP 5 hp, 13 CFM at 90 PSICF
- Generates 21-40% enriched air nitrox (EANx)
- Nuvair 6 CFM membrane system
- Pro O2 Analyzer for oxygen
- Pick O2 Analyzer for permeate in-line oxygen
- 110 or 220 V thermostatically controlled heater
- LP > LP regulator for nitrox percentage adjustment
- LP supply pressure and regulated pressure gauges
- Hankison Series 16 LP filtration pack
- NorthStar e420 9.8 hp EFI horizontal OHV gas engine, electric start, 3A charging system
- Tachometer/hour meter
- 600-watt inverter
- 12V battery
Options
- Automatic condensate drains
- High temperature shutdown
- Automatic fill pressure shutdown
- Norgren Series 74 LP filtration pack, auto drains/dual pressure gauges, coalescing 1.0 micron, polishing .01 micron, oil vapor removal .003 ppm
- Preset maximum fill blocks 3000 psi (207 bar) and 4500 psi (310 bar)
- Solar charger
- Electric motor: 208-220V single or three phase, 50 or 60 Hz
Specifications
| Traveler II Model Number |
Gas SKU 7052G |
Electric SKU 7052E |
|
|---|---|---|---|
| Physical Specifications | L x W x H Weight |
23 x 57 x 49 in (58 x 145 x 124 cm) 430 lb (195 kg) |
23 x 57 x 49 in (48 x 145 x 124 cm) 430 lb (195 kg) |
| LP Compressor | Capacity | 13 CFM (425 L/min) Capacity @ 175 psi |
13 CFM (425 L/min) Capacity @ 145 psi |
| Volume Tank | Capacity | 15 gal (57 L) | 15 gal (57 L) |
| Membrane Input | Operating Pressure Supply Air Volume Optimum Temperature |
90-165 psi (6-11 bar) 2-4 CFM (57-113 L/min) 110 ±5°F(43 ±3°C) |
90-165 psi (6-11 bar) 2-4 CFM (57-113 L/min) 110 ±5°F(43 ±3°C) |
| HP Nitrox Compressor | Output Charging Rate* Fill Time* Power - Electric Power - Gas |
3.5 CFM, (100 L/min) 4.2 SCFM (119 L/min) ~22 minutes N/A 11 hp (8.2 kW) |
3.5 CFM, (100 L/min) 4.2 SCFM (119 L/min) ~22 minutes 7.5 hp (5.5 kW) N/A |
* Fill time based on 80 cu ft cylinder from 500 to 3000 psi.
