120 Gallon, 200 psi Grasshopper Volume Tank

This ~120-gallon grasshopper-style volume tank (air receiver) is ASME rated. Measures 24 in O.D. x 67 in L. Special interior and exterior coatings can be quoted to meet your specifications. Maximum working pressure: 200 psi.



This low-pressure air receiver is built in accordance with the ASME Section VIII Division I code latest addition. Quotes for special interior and exterior coating options available.

SKU A10126
Volume ~120 gal
Cubic Feet ~19.2
Material Carbon Steel
Exterior Finish Standard Shop Primer
Interior Finish As Welded, Unifinished
MAWP 200 psi @ 450°F
MDMT -20°F @ 200 psi
O.D. 24 in
Length 67 in
Shipping Weight 492 lb
Additional Equipment  Tank only
Schematic Nozzles
N1 1/4 NPT
N2 3/4 NPT
N3 1-1/2 NPT
N4 2 NPT
