Male Branch Tees Stainless

Stainless steel male branch tee connects fractional tube to female NPT thread. Various sizes available.

SKU
TTM-316 Series
Grouped product items
Product Name Qty
1/8" x 1/8" MNPT Branch Tee Stainless | 2TTM2-316
$39.50
1/4" Tube x 1/8" MNPT Branch Tee Stainless | 4TTM2-316
$37.50
1/4" Tube x 1/4" MNPT Branch Tee Stainless | 4TTM4-316
$51.00
3/8" Tube x 1/4" MNPT Branch Tee Stainless | 6TTM4-316
$48.00
1/2" Tube x 3/8" MNPT Branch Tee Stainless | 8TTM6-316
$72.75
1/2" Tube x 1/2" MNPT Branch Tee Stainless | 8TTM8-316
$87.60
3/4" Tube x 3/4" MNPT Branch Tee Stainless | 12TTM12-316
$114.75

Specifications

SKU 2TTM2-316 4TTM2-316 4TTM4-316 6TTM4-316 8TTM6-316 8TTM8-316 12TTM12-316
Material Stainless Steel
D Tube O.D. 1/8 (3.17) 1/4 (6.35) 1/4 (6.35) 3/8 (9.52) 1/2 (12.7) 1/2 (12.70) 3/4 (19.05)
T (NPT) 1/8 1/8 1/4 1/4 3/8 1/2 3/4
d Min. 2.28 4.82 4.82 7.11 10.41 10.41 15.74
h 1/2 (12.7) 1/2 (12.7) 1/2 (12.7) 5/8 (15.87) 13/16 (20.63) 13/16 (20.63) 1-1/16 (26.98)
H 7/16 (11.11) 9/16 (14.28) 9/16 (14.28) 11/16 (17.46) 7/8 (22.22) 7/8 (22.22) 1-1/8 (28.57)
A 12.70  15.24  15.24  16.76  22.86  22.86  24.38
B 15.24  17.78  17.78  19.30  21.84  21.84  21.84
17.00  19.55  19.71  23.11  25.90  25.90  28.19
L 24.91  26.92  27.08  30.48  36.06  36.06  38.35
L1  17.80  18.79  23.87  25.40  28.19  33.02  36.83
