Dry Pressure Gauge: 7500 psi, 2.5 in Dial, Stainless Center Back Case

$31.06

7500 psi (517 bar) stainless steel pressure gauge with dampened movement. 2.5 in dry dial. Wetted parts: Brass tube and socket. Center back 1/4 in NPT.

SKU
SCC63-1-7500-D-DBR

Specifications

Configuration Stainless case center back
Dampened movement
Gauge Size 2.5 in (63mm)
Wetted Parts Brass tube and socket
Connection 1/4 NPT
Range 0–7500 psi
Fill Dry no fill
Dial Dual scale (psi and bar)
Accuracy 2%-1%-2%
Design ANSI/ASME B40.1
Operating Temperture -40°F to 150°F
Temperature Error Additional error when temperature changes from reference temperature of 68°F (20°C)
±0.4% for every 18°F (10°C) rising or falling as a percentage of span.
Weather Protection Weather tight (NEMA 4X / IP 65)
Replaces SKU 25.410.7500 & 25.911.7500
