Quincy 325 with Honda Gas
Quincy 325 low pressure compressor with pressure lubrication and loadless start with head unloaders. This package has a one-gallon surge/manifold tank, ball valve output, over-pressure valve, drain valve, large air aftercooler, check valve, gate valves and plumbing. The Honda gas engine features key electric start or pull start, tach/hour meter and battery box. The frame is made with 6061 aluminum and has an enclosed bottom, four-point lifting eyes, handles and wheels making it easy to move on and off the job. All equipment is inset; compressor and diesel are mounted on an aluminum plate and have independent vibration absorption mounts. This package requires a low pressure gas receiver (volume tank) for use.
Features
- Quincy 325 LP compressor
- Electric start 11.7 hp Honda gas engine
- Tach / hour meter
- Aluminum frame with enclosed bottom, lifting eyes, handles and wheels
- Aluminum belt guard
- Over pressure, drain and check valves
- 12 V sealed battery
- 1.61 gal fuel tank
- Air cooled aftercooler
Options
- Steel or stainless steel frame
- Monitors/alarms: CO, CO2, O2, H2S, low pressure, and high temperature
- Three-stage breathing air filtration
- 30 gal volume tank
- 250 or 300 psi
Specifications
| SKU | Q-325H | Q325HL |
|---|---|---|
| Flow Rate | 19 CFM (528 L/min) | 19 CFM (528 L/min) |
| Engine Power | 11.7 hp (8.7 kW) | 11.7 hp (8.7 kW) |
| Max Operating Pressure | 175 psi (12 bar) | 175 psi (12 bar) |
| Number of Stages | 2 | 2 |
| Lubrication | Pressure | Pressure |
| Air Quality | N/A | Grade D Breathing Air |
| Dimensions (L x W x H) |
48 x 29 x 38 in (122 x 71 x 96 cm) |
48 x 29 x 61 in |
| Weight | 531 lb (247 kg) | 679 lb (313 kg) |
