Quincy 5120 25 hp Weg Electric Low Pressure Compressor
Used in the production of low pressure air, the Quincy 5120 electric framed-in package provides 87 CFM (2464 L/min) at 175 psi. Years of proven dependability as an industry workhorse this is the standard in many dive companies and industrial uses worldwide. Our electric package includes a 5120 compressor block with head unloaders and Weg TEFC 25 hp motor with NEMA 4 starter box and belt guard mounted in a powder coated steel frame.
SKU
Q-5120-E
Features
- High quality, reliable electric motor
- Low oil carry over compressor rings
- LVD control
- Air cooler
- Two ASME rated 60-gallon volume tanks
- Simple to operate, reliable, and versatile
Options
- Low pressure regulator for downstream pressure
- CO and/or CO2 analyzers
- Audible and visual alarms for high temperature, low oil and carbon monoxide
- Shutdown for high temperature, low oil and carbon monoxide
- Stainless steel volume tanks
- Certified frame / lifting eyes
- 30 hp motor @ 95 CFM (2690 L/min)
- 250 psi (17 bar)
Specifications
| Charging Rate | 87 CFM (2464 L/min) @ 175 psi |
|---|---|
| Engine | 230 / 415 / 460 V E3 / 50 or 60 Hz |
| Engine Power | 25 hp (18.6 kW) |
| Max Operating Pressure | 200 psi (14 bar) |
| RPM | 951 |
| Number of Stages | 2 |
| Lubrication | Pressure |
| Air Quality | Grade D Breathing Air |
| Dimensions (L x W x H) |
96 x 55 x 48 in (244 x 140 x 122 cm) |
| Weight | 2900 lb (1315 kg) |
