Stainless Tube x Tube Union & Reducing Tee Series
Stainless steel tube to tube union tees and reducing tees in multiple sizes. Connects fractional tubes. Temperature rating: -425°F to 1200°F (-245°C to 649°C).
SKU
TTT-316 Series
Union Tee Specifications
| SKU | D Tube O.D. | d Min. | h | H | A | B | ℓ | L |
|---|---|---|---|---|---|---|---|---|
| 2TTT-316 | 1/8 (3.17) | 2.28 | 3/8 | 7/16 | 12.7 | 15.24 | 15.74 | 22.35 |
| 4TTT-316 | 1/4 (6.35) | 4.82 | 1/2 | 9/16 | 15.24 | 17.78 | 19.55 | 26.92 |
| 6TTT-316 | 3/8 (9.52) | 7.11 | 5/8 | 11/16 | 16.76 | 19.30 | 23.11 | 30.48 |
| 8TTT-316 | 1/2 (12.7) | 10.41 | 13/16 | 7/8 | 22.86 | 21.84 | 25.90 | 36.06 |
Reducing Tee Specifications
- SKU 6TTT4-316: 3/8 × 1/4 × 1/4 in Stainless Steel Reducing Union Tee
- SKU 8TTT4-316: 1/2 × 1/2 × 1/4 in Stainless Steel Reducing Union Tee
