1-1/2" Crouse-Hinds Liquidtight Insulated Malleable 90º Connector
$47.66
Crouse-Hinds Liquidator™ liquidtight flexible metallic conduit fittings are used when liquidtight conduit is in tough, industrial and corrosive applications. Insulated 1-1/2" 90° angle connector. Finish: Malleable iron - zinc electroplated.
SKU
LTB15090
Features
- Liquidtight, raintight, oiltight for protection and long life in wet, dusty and corrosive environments
- Hex shaped gland nut allows for easy wrenching, providing a fast, tight installation
- Suitable for wet locations
- Reusable, long ferrule prevents pull-out and tight bend conduit pop-out
- Furnished with locknut and sealing ring
- Third party certified
Specifications
| SKU | Trade Size | Weight | A | B | C |
|---|---|---|---|---|---|
| LTB15090 | 1-1/2" | 1.2 lb | 3.063" | 0.750" | 2.438" |
Certifications and Compliances
- UL Listed liquidtight flexible metal conduit fittings are suitable for use in the following hazardous locations under NEC:
- Class I, Division 2;
- Class II, Divisions 1 & 2; and
- Class III, Divisions 1 & 2;
- Suitable for grounding in sizes 3/8 in through 1-1/4 in under NEC - UL Standards 514B, 467
- cUL Standard C22.2 No. 18F
- UL File No. E-19189
