1/4 in MNPT Brass Flow Reducing Hex Nipple 1-3 L/min
$14.58
1/4 in Male NPT x 1/4 in Male NPT brass flow reducing hex nipple. Produces air flow of 1-3 L/min depending on input pressure.
SKU
9517.6
Uses
- Precision flow control – gases or liquids
- Speed controls – cylinders and actuators
- Accurate timing in pneumatic or hydraulic Circuits
- Flow restriction
- Accurate throttling
- Snubbers - gauges and instruments
- Ultrasonic sound sources
Advantages
- High pressure capability
- Bi-directional flow compatibility
- Economical precision orifice
- Repeatable orifice size and shape
- Predictable flow rate
Details
| Maximum Operating Pressure | 2000 psi |
|---|---|
| Orifice Diameter | 0.0059 in |
| Width Across Flats (Hex) | 9/16 in |
| Total Length | 1.3800 in |
| Air Flow at Pressure: L/min | 1 psi: 0.086 10 psi: 0.31 100 psi: 1.58 15 psi: 0.39 20 psi: 0.46 25 psi: 0.53 30 psi: 0.60 40 psi: 0.7 45 psi: 0.21 50 psi: 0.88 60 psi: 1.02 70 psi: 1.16 80 psi: 1.30 90 psi: 1.44 |
| Air Flow at Vacuum: L/min | 10 inHg: 0.168 65 inHg: 0.129 |
