Tube to Female Pipe Connector Series

Stainless steel Female NPT straight fitting connects fractional tube to Male NPT thread.
SKU
CF-316 Series
Grouped product items
Product Name Qty
1/8" Tube x 1/8" FNPT | 2CF2-316
$15.50
1/8" Tube x 1/4" FNPT | 2CF4-316
$17.75
1/4" Tube x 1/8" FNPT | 4CF2-316
$15.00
1/4" Tube x 1/4" FNPT | 4CF4-316
$21.20
3/8" Tube x 1/4" FNPT | 6CF4-316
$21.60
1/2" Tube x 3/8" FNPT | 8CF6-316
$27.25
1/2" Tube x 1/2" FNPT | 8CF8-316
$37.50

Specifications

SKU D
Tube O.D.
T
NPT
d
(Min.)
h
Width Across Flat
H
Width Across Flat

A
(mm)

B
(mm)

(mm)
L
(mm)
2CF2-316 1/8 (3.17mm) 1/8 2.28 9/16 7/16 12.70 15.24 22.09 28.70
2CF4-316 1/8 (3.17mm) 1/4 2.28 3/4 7/16 12.70 15.24 26.92 33.52
4CF2-316 1/4 (6.35mm) 1/8 4.82 9/16 9/16 15.24 17.78 23.87 31.24
4CF4-316 1/4 (6.35mm) 1/4 4.82 3/4 9/16 15.24 17.78 28.44 35.81
6CF4-316 3/8 (9.52mm) 1/4 7.11 3/4 11/16 16.76 19.30 30.22 37.59
8CF6-316 1/2 (12.7mm) 3/8 10.41 7/8 7/8 22.86 21.84 31.75 41.91
8CF8-316 1/2 (12.7mm) 1/2 10.41 1-1/16 7/8 22.86 21.84 36.57 46.73
