45" (1.14m) of 3/16" 5000 psi Thermoplastic Air Hose w/ Stainless Ends


45" length (1.14m) of high-pressure 3/16" diameter thermoplastic air hose with stainless steel hose ends. 5000 psi (345 bar) working pressure; commonly used for breathing air. Hose ends: (1) Stainless Steel 1/4 Male Rigid, and (1) Stainless Steel #4 JIC Female Swivel.


Hose Specifications

520N is a thermoplastic high pressure hose that meets SAE 100R8 specifications and offers great flexibility, cover durability, and reduced weight.

SKU 520N-3
Hose I.D. 3/16"
Maximum O.D. 0.43"
Minimum Bend Radius 1.5"
Weight 0.05 lb/ft (0.07 kg/m)
Tube Nylon
Reinforcement Aramid fiber
Cover Perforated Polyurethane (color: black)
Maximum Working Pressure 5000 psi (345 bar)
Working Temperature Range -40°F to +212°F (-40°C to +100°C)
Minimum Burst Pressure 4x maximum working pressure at 73°F (23°C)
Vacuum Rating 28 inHg

Hose Ends

SKU 10655-4-3SS

SKU 10155-4-3-SS

Stainless Steel 1/4 Male Rigid x 3/16 Rigid Hose End

Hose I.D. = 3/16"

Style = Male (JIS)/BPST - Rigid - Straight

SKU 10655-4-3SS

SKU 10655-4-3SS

Stainless Steel #4 JIC Female x 3/16 Swivel Hose End

Hose I.D. = 3/16"

Style = Female JIC 37° - Swivel - Straight
