Reducing Regulator 6000 psi In MNPT > 0-5000 psi Out FNPT Aluminum
Aqua Environment anodized aluminum reducing regulator with maximum rated pressure: 6000 psi (414 bar). Outlet pressure range: 0-5000 psi (0-345 bar). Outlet pressure rating: 5000 psi (345 bar). The model 1120 is a small, piston type, hand load regulator available in an outlet pressure range of 0 to 5000 psi (0-345 bar) with a single inlet and outlet port. It is available with a hex head adjusting bolt and lock nut for single set pressure use or with the same adjusting hand knob. It can be panel mounted using either the upper 1.25" threaded section and lock nuts or the lower 1" jam nut. It uses an unbalanced poppet design for ruggedness and simplicity. There is a small variation of control pressure with changing inlet pressure as noted in the specifications. A 20 to 30 micron filter in the poppet cartridge prevents damage by contaminants.
Specifications
| Type | Hand load reducing regulator |
| Special Features | Single outlet |
| Maximum Rated Pressure | 6000 psi (414 bar) |
| Outlet Pressure | 0-5000 psi (0-345 bar) |
| Outlet Pressure Rating | 5000 psi (345 bar) |
| Body Ports | 1/4" MNPT - inlet at the bottom centerline 1/4" FNPT - outlet on the side as shown |
| Flow coefficient (Cv) | 0.06 (equals 0.07 in orifice) |
| Outlet Pressure Variation with Inlet Pressure |
70 psi rise/1000 psi inlet drop |
| Leakage | Bubble Tight |
| Weight | 14.1 oz (400 g) |
| Overall Length | 6" (15.24 cm) |
| Hex Diameter | 1-3/8" |
| Minimum Temperature | -15°F (-26°C) |
| Body Material | Anodized Aluminum |
| Internal Materials | Brass Stainless |
| Seal Materials | Kel-F Viton |
Typical Applications
- Component testing
- Air tank fill stations
- Firefighting air systems
- Instrument and calibration panels
- Process industry control
- Shipboard and offshore air and gas control
- Electronic industry rare gas flow
- Vehicle stations
