Haskel Air Pilot Switch 3W,NC,0.15K-0.7K,O2
$993.34
An air pilot switch is a pressure switch that produces a pneumatic signal up to 150 psi at any sensing pressure within their adjustment range. The signal valve may be piped normally open (NO), normally closed (NC), 3-way, or 2-way, depending on the model. All models use a 2-position poppet-type air signal valve which is shifted from its normal position by a rod from the sensing end which first must overcome an adjustable force spring (styles A and C) or air-regulated dome loader (style B). For additional information, see pp. 4-7 in the document located under the Brochure tab.
SKU
28755-13
Specifications
| SKU | 28755-13 |
|---|---|
| Style | C |
| Gas | Oxygen (O2) |
| Maximum Sensing Pressure | 5000 psi |
| Air Valve | 3-way, NC |
| Adjustable Range | 150–700 psi |
| Approximate Length | 5-11/16 in |
| Approximate Outside Diameter | 1-3/8 in |
| Ports: Air (2) | 1/8 in NPT (vented not threaded) |
| Ports: Sensing (3) | 1/4 in NPT |
