Membrane Pressure Switch · 40 psi Open 80 psi Close
$36.24
Operates with Nuvair nitrox membrane system. Encapsulated, non-adjustable, SPST direct mount switch. Low pressure switch opens on pressure fall. Snap acting hermetically sealed sensor.
SKU
B16-947
Specifications
| DC Voltage | 6 / 12 / 36 |
|---|---|
| Tolerance | ±5 psi |
| Open Pressure | 40 psi |
| Closed Pressure | 80 psi |
| Burst Pressure | 2800 psi |
| Maximum Operating Pressure | 700 psi |
| Maximum Temperature | -31°F to 149°F (-35°C to 65°C) |
| Maximum LRA | 17.4 A @ 240 VAC |
| Maximum LRA | 34.8 A @ 120 VAC |
| Maximum FLA | 2.9 A @ 240 VAC |
| Maximum FLA | 5.8 A @ 120 VAC |
| Life at Rated Load | 100,000 cycles |
| Wire | 18 AWG 18" long |
