13.3 Gallon, 200 psi Horizontal Volume Tank

This 13.3-gallon horizontal volume tank is ASME rated. Measures 14 in O.D. x 23 in L. Foot brackets: 2 in H. Special interior and exterior coatings can be quoted to meet your specifications. Maximum working pressure: 200 psi.



This low-pressure air receiver is built in accordance with the ASME Section VIII Division I code latest addition. Vessels are "U" stamped and registered with National Board. Two tanks of different finishes are listed below. Quotes for special interior and exterior coating options available.

SKU 304938 304938-PC-YL01
Volume 13.3 gal 13.3 gal
Cubic Feet 1.8 1.8
Material Carbon Steel Carbon Steel
Exterior Finish Standard Shop Primer Powder Coated Yellow
Interior Finish As Welded, Unfinished As Welded, Unfinished
Working Pressure (psi) 200 200
Operating Temperature ≤650°F ≤650°F
O.D. 14 in 14 in
Length 23 in 23 in
Weight 44 lb 50 lb
Square Feet 7.6 7.6
Additional Equipment Tank Only Tank Only
